ZAi-H30T Enterprise Camera Payload

Key Highlights of ZAi-H30T Enterprise Payload

Key Highlights of ZAi-H30T Enterprise Payload
24/7 night vision with NIR light
Integrated 5-in-1 enterprise payload
400x maximum digital zoom
1280 x 1024 1024 high-resolution thermal imaging
3000-meter laser rangefinder turns

Upgrade to the ZAi-H30T Enterprise Payload

The ZAi-H30T is a premier, all-weather drone payload designed for demanding operations. Integrating five advanced sensors, this versatile enterprise payload delivers exceptional zoom, high-resolution thermal imaging, and precise laser ranging. It stands as the ultimate gimbal camera solution for professionals seeking unmatched situational awareness and reliability.

enterprise payload
dji payload
dji h30t
dji enmuse h30t
dji h30 series

Key Benefits of ZAi-H30T Enterprise UAV Payload

Integrated Multi-Sensor Power
Integrated Multi-Sensor Power

Combines five high-performance sensors—visible, thermal, laser, and auxiliary light—into one payload for unparalleled versatility in any mission context.

Exceptional Long-Range Zoom
Exceptional Long-Range Zoom

Delivers up to 400x magnification, allowing users to capture precise, actionable details from safe distances without compromising situational awareness.

High-Resolution Thermal Imaging
High-Resolution Thermal Imaging

Features 1280 x 1024 thermal resolution and extensive temperature range, dramatically improving target detection and analysis for critical operations.

Advanced Night Scene Operations
Advanced Night Scene Operations

Utilizes powerful NIR light and dedicated algorithms to ensure clear, high-contrast visible imagery in challenging low-light and nighttime environments.

Precise Long-Distance Ranging
Precise Long-Distance Ranging

Integrated laser rangefinder accurately measures target distance and coordinates up to 3000 meters, enabling efficient and accurate team coordination.

Unmatched Durability and Reliability
Unmatched Durability and Reliability

Boasts IP54 ingress protection and extreme temperature tolerance, ensuring robust, stable operation and data integrity in harsh environmental conditions.

ZAi-H30T Enterprise Payload Specifications

1. General Specifications
ParameterOfficial Specification
ParameterOfficial Specification
Product NameZenmuse H30T (ZAI-H30T)
Dimensions170 × 145 × 165 mm (L×W×H)
Weight920 ± 5 g
Power Consumption28 W
IP RatingIP54 (IEC60529 standard)
Supported AircraftMatrice 350 RTK, Matrice 300 RTK (requires DJI RC Plus)
Gimbal Controllable RangeTilt: -120° to +60°; Pan: ±320°
2. Infrared Thermal Camera
ParameterOfficial Specification
Thermal SensorUncooled VOx Microbolometer
Thermal Resolution1280 × 1024 @ 30fps
Lens SpecsFocal Length 24 mm (52 mm equivalent), f/0.95, DFOV 45.2°
Digital ZoomUp to 32x equivalent
Temperature RangeHigh Gain: -20°C to 150°C; Low Gain: 0°C to 600°C (up to 1600°C with Infrared Density Filter)
Photo / Video FormatPhoto: R-JPEG (16-bit); Video: MP4 (H.264/H.265)
Thermal Sensitivity (NETD)≤ 50 mk @ f/1.0
3. Zoom Camera
ParameterOfficial Specification
Image Sensor1/1.8-inch CMOS, 40 MP effective pixels
Focal Length7.1-172 mm (33.4-809.3 mm equivalent)
Max Aperturef/1.6 - f/5.2
Optical Zoom34x Hybrid Optical Zoom
Max Zoom400x Max Digital Zoom
Max Video ResolutionSingle shot: 3840 × 2160 @ 30fps; Night Scene: 1920 × 1080
ISO RangeNormal: 100 - 25600; Night Scene Mode: 100 - 819200
4. Wide-Angle Camera & Laser Range Finder (LRF)
ParameterOfficial Specification
Wide Sensor1/1.3-inch CMOS, 48 MP effective pixels
Wide LensFocal Length 6.72 mm (24 mm equivalent), f/1.7, DFOV 82.1°
Laser Wavelength905 nm
LRF Measurement Range3 m to 3000 m
NIR Auxiliary Light850 nm wavelength, Class 1 safety rating


Technical Consultation & Project Requirements

Share your mission specifications—such as payload capacity, endurance needs, or environmental constraints. Our engineering team will review your data and provide a optimized UAV configuration tailored to your industrial workflow.
